Odoo Cloud Telephony Integration (CTI & Call Sync) — A build-to-order integration that connects your Odoo instance to your cl — 1/1Illustrative preview

A build-to-order integration that connects your Odoo instance to your cloud phone system for click-to-dial,

incoming-call screen-pop, and two-way contact synchronization.

ECOSIRE scopes, builds, installs, and supports it — this is not an off-the-shelf download.

What is Odoo Cloud Telephony Integration (CTI & Call Sync)?

A build-to-order integration that connects your Odoo instance to your cloud phone system for click-to-dial, incoming-call screen-pop, and two-way contact synchronization. ECOSIRE scopes, builds, installs, and supports it — this is not an off-the-shelf download. Built to order by ECOSIRE for Odoo 17, 18, 19 — indicative price from $999.00 USD; request a quote for a scoped proposal.

Key Features

Click-to-dial buttons on `res.partner`, `crm.lead`, and `helpdesk.ticket` that place calls via the provider's telephony REST API
Inbound screen-pop: a signed webhook controller matches the caller ID against `res.partner` and opens the record in an OWL overlay
One-click contact creation from an inbound call when no `res.partner` match is found, pre-filling name and number
Dedicated call-log model (`models.Model`) capturing direction, duration, agent, linked record, and disposition per call
`compute`/`@api.depends` fields for derived values such as human-readable duration and normalized E.164 numbers
Automatic chatter logging: each connected call drops a structured `mail.message`/activity onto the linked record
Two-way contact synchronization via scheduled `ir.cron` with an optional real-time webhook path
Configurable conflict-resolution policy (Odoo-wins, provider-wins, or newest-wins) for contact sync collisions
Encrypted storage of provider API keys and endpoints in `ir.config_parameter` system parameters, never hard-coded
Row-level security through `ir.model.access.csv` plus record rules so agents see only their own call records
Agent extension mapping model linking Odoo users to their telephony extensions/seats for correct call attribution
QWeb call-summary report and filterable call-log list/kanban/pivot views for reporting
Automated action / server-action hooks so missed inbound calls can raise a follow-up activity automatically
Structured error handling and a sync-status dashboard surfacing failed API calls and webhook retries

Built to order, done for you

No DIY setup — a working app, built, installed and supported by ECOSIRE.

  1. 1

    You order

    Start with a one-time build price. We scope it with you at kickoff.

  2. 2

    We build & install

    ECOSIRE builds, configures and installs it on your Odoo.

  3. 3

    Go live + support

    You go live in about one working week, with two weeks of go-live support. Defects in the code we deliver are fixed free of charge.

Technical Specifications

Odoo Compatibility
Odoo 17, Odoo 18, Odoo 19
Editions
Enterprise & Community
License
Licence confirmation required
Python Requirement
Python 3.10+
Database
PostgreSQL 12+

About this Product

Sales and support teams that live inside Odoo still jump to a separate phone app to dial, log calls by hand, and reconcile contact lists that drift apart between the two systems. Every un-logged call is a gap in the CRM timeline; every manually keyed number is a chance to misdial; every new contact created in the phone system never makes it back to res.partner. Odoo core has a phone field and the mail.thread chatter, but it has no native computer-telephony (CTI) bridge to a cloud voice provider — no click-to-dial, no inbound screen-pop, no automatic call logging, and no contact reconciliation. That last-mile gap is exactly where teams lose call context and clean data.

ECOSIRE builds a made-to-order integration module that wires your Odoo instance directly to your cloud telephony platform. On the outbound side, we add click-to-dial controls on res.partner, CRM leads, and helpdesk tickets that trigger a call through the provider's telephony API and drop a structured activity/log row into the record's chatter the moment the call connects or ends. On the inbound side, a lightweight CTI listener (webhook receiver plus an OWL/JS overlay) matches the caller's number against res.partner and pops the matching record — or offers one-click contact creation when there's no match. Two-way contact sync runs as a scheduled ir.cron job (and optional real-time webhooks) to keep numbers, names, and ownership aligned between Odoo and the phone system, with a conflict policy you choose during scoping.

Under the hood this is a proper Odoo addon, not a bolt-on script. We define a dedicated model layer (models.Model) for call records, extension mappings, and sync state, with compute/@api.depends fields for derived values like call direction and duration formatting. Provider credentials and endpoints are stored in encrypted system parameters, access is locked down through ir.model.access.csv plus record rules so agents only see their own calls, and every UI surface — the dial widget, the incoming-call overlay, the call-log views, and QWeb call-summary reports — ships as versioned XML/OWL. Outbound requests use the provider's REST API; inbound events arrive on a signed webhook controller; and the whole module speaks Odoo's own XML-RPC/JSON-RPC conventions so it composes cleanly with the rest of your database. We build against your exact Odoo edition and note Community-vs-Enterprise differences (for example where Enterprise VoIP widgets already exist) so we extend rather than collide. Supported on Odoo 17.0, 18.0, and 19.0.

Delivery is build-to-order. After a short scoping call we confirm your telephony provider, call-flow rules, and sync policy, then build on a staging copy of your database, run UAT with your team, and cut over with a rollback plan. Typical delivery is one working week from confirmed scope. Pricing starts from $999 (indicative, single-company base scope); additional call-handling extensions, multi-company routing, real-time (vs scheduled) contact sync, and larger historical call-data migration increase the quoted scope. You get a fixed quote after the scoping call — never a surprise invoice.

What you get

  • Installable, version-pinned Odoo addon source for your target edition (17.0, 18.0, or 19.0)
  • Installation and configuration on your environment, including provider API credentials and webhook endpoint setup
  • Technical documentation: data model, `ir.model.access.csv` rules, cron/webhook flows, and configuration reference
  • End-user guide plus a live training session for agents and admins
  • UAT on a staging copy of your database with a documented, tested rollback plan
  • Post-go-live support window for defect fixes and configuration tuning
  • Git repository handover with full commit history and tagged release
  • Provider-integration runbook covering credential rotation, webhook re-registration, and sync troubleshooting

Who this is for

Inside sales team lead

Runs an outbound-heavy sales floor in Odoo CRM and wants reps dialing from the lead record with every call auto-logged to the timeline — no more manual call notes or copy-pasted numbers.

Customer support manager

Handles inbound support through Odoo Helpdesk and needs incoming calls to screen-pop the caller's ticket history instantly, plus missed-call follow-up activities so nothing slips.

Odoo administrator / IT owner

Owns the Odoo instance and the telephony contract, and needs a secure, maintainable integration with encrypted credentials, scoped access rules, and a clean git handover rather than a fragile one-off script.

Operations / RevOps lead

Wants one clean contact list across the phone system and Odoo, reliable call-activity data for reporting, and a defined sync-conflict policy so the two systems stop drifting apart.

How Odoo Cloud Telephony Integration (CTI & Call Sync) Compares

CriterionECOSIRECustom BuildCompetitorOdoo Native
Fit to your telephony provider & call flowsBuilt to your exact provider, extensions, and routing rulesFully bespoke but you own all design decisionsFixed to the vendor's supported providers onlyNo CTI bridge to any external phone system
Click-to-dial & inbound screen-popBoth, on partner/lead/ticket via OWL widgetsWhatever you specify and can buildOften one direction or provider-limitedNot available in core (partial in Enterprise VoIP)
Automatic call logging to chatterStructured activity/log on every connected callPossible, needs designing from scratchVaries; often basic note onlyManual notes only
Two-way contact syncScheduled `ir.cron` + optional webhooks, with conflict policyBuildable but you define the policyFrequently one-way or absentNone
Security & access controlEncrypted params, signed webhooks, record rulesDepends on your build disciplineVendor default; limited configurabilityStandard Odoo ACLs, no telephony layer
Source code & ownershipFull source + git repo handoverYou own it, but you build & maintain itClosed/licensed, no sourceN/A
Delivery & support2-4 wks, UAT + rollback + support windowDepends on your team's capacityInstant install, self-support/ticketsIncluded in Odoo, no telephony scope
Odoo 17/18/19 compatibilityBuilt and pinned to your target versionYour responsibility to maintainDepends on vendor's release cadenceCore evolves each release

Frequently Asked Questions about Odoo Cloud Telephony Integration

How long does delivery take?

This is a build-to-order integration, so we build it against your specific telephony provider and call flows. Typical delivery is one working week from confirmed scope. After the scoping call we give you a firm timeline alongside the fixed quote; larger call-data migrations or multi-company routing can extend it, and we'll tell you that up front.

Is this an existing app I can download and install today?

No. It is not an off-the-shelf marketplace download. ECOSIRE designs, builds, installs, and supports the module specifically for your Odoo edition and phone system. You receive installable source and the git repository once your version is built and accepted in UAT.

How does pricing and scoping work?

Pricing starts from $999 (indicative, single-company base scope). The final price depends on your provider, the number of call-handling extensions, real-time vs scheduled contact sync, multi-company needs, and any historical call-data migration. We hold a short scoping call, then give you a fixed quote — no surprise invoicing.

Which Odoo versions and editions do you support?

We support Odoo 17.0, 18.0, and 19.0 on both Community and Enterprise. Where Enterprise already ships VoIP widgets, we extend and complement them rather than duplicate; on Community we provide the full click-to-dial, screen-pop, and logging layer ourselves. We confirm the exact edition during scoping.

What about support and future updates?

Every build includes a post-go-live support window for defect fixes and configuration tuning. Because you receive the full source and git repository, you're never locked in. We also offer ongoing support and version-upgrade engagements (for example migrating the module to a newer Odoo release) as a separate, quoted arrangement.

Will this work with our specific phone system?

It's designed to integrate with a cloud telephony platform that exposes a REST/telephony API and webhooks for inbound events. During the scoping call we confirm your provider's API capabilities and map them to click-to-dial, screen-pop, and sync. If a capability isn't available on your plan, we flag it before you commit.

How is our data and access kept secure?

Provider API credentials are stored as encrypted system parameters (`ir.config_parameter`), never hard-coded. Inbound webhooks are signature-verified, and call records are protected with `ir.model.access.csv` plus record rules so agents only see their own calls. Everything follows Odoo's standard security model.

Request a quote

Odoo Cloud Telephony Integration

A build-to-order integration that connects your Odoo instance to your cloud phone system for click-to-dial, incoming-call screen-pop, and two-way contact synchronization. ECOSIRE scopes, builds, installs, and supports it — this is not an off-the-shelf download.

  • Click-to-dial buttons on `res.partner`, `crm.lead`, and `helpdesk.ticket` that place calls via the provider's telephony REST API
  • Inbound screen-pop: a signed webhook controller matches the caller ID against `res.partner` and opens the record in an OWL overlay
  • One-click contact creation from an inbound call when no `res.partner` match is found, pre-filling name and number
  • Dedicated call-log model (`models.Model`) capturing direction, duration, agent, linked record, and disposition per call
